Konetool manufactures top-quality industrial TCT planer blades with micro-grain and sub-micron-grain tungsten carbide for major brand planing machines like SCM.
Material: KF21T grade tungsten carbide
Applications: Wood, softwood, hardwood, laminated
Machines: Weinig, Wadkin, SCM, Leadermach, etc
Request for quotation for detailed information (MOQ, price, delivery, etc).
Compared to HSS planer blades, TCT planer blades feature 4 to 7 times higher cutting speed and 5 to 80 times the longer service life, which means carbide-tipped planer blades can stay in shape for a much longer time. Meanwhile, carbide planer blades are more economical than solid carbide planer blades. Konetool has been devoted to planer blades manufacturing for 10 years. We have full CNC production lines as well as advanced inhouse facilities, ensuring the quality and production of our carbide planer blades. Besides, a mature supply chain, rich global trade experience, strict quality inspection, efficient delivery, competitive price, and responsible sales team and engineers will contribute a lot to your perfect purchasing experience at Konetool.
Make an inquiry for detailed information (MOQ, price, delivery, etc) or request our TCT planer knives catalog. Our salespeople and technicians will work together to provide you with the most cost-efficient solution.
Features:
| Grade | Grain Size | Density (g/cm³) | Hardness (HRa) | T.R.S (N/mm²) |
| KF21T | Submicron | 14.75-14.95 | 92.8-93.5 | 3000 |
Machines:
Cutting Materials:
Specifications:
| Order NO. | Overall length (mm) | Width (mm) | Thickness (mm) | Cut Angle (α°) |
| M0P100AT10 | 100 | 25 | 3 | 45 |
| M0P130AT10 | 130 | 25 | 3 | 45 |
| M0P200AT10 | 200 | 25 | 3 | 45 |
| M0P210AT10 | 210 | 25 | 3 | 45 |
| M0P255AT10 | 255 | 25 | 3 | 45 |
| M0P310AT10 | 310 | 25 | 3 | 45 |
| M0P330AT10 | 330 | 25 | 3 | 45 |
| M0P410AT10 | 410 | 25 | 3 | 45 |
| M0P455AT10 | 455 | 25 | 3 | 45 |
| M0P510AT10 | 510 | 25 | 3 | 45 |
| M0P600AT10 | 600 | 25 | 3 | 45 |
| M0P630AT10 | 630 | 25 | 3 | 45 |
| M0P100BT10 | 100 | 30 | 3 | 45 |
| M0P130BT10 | 130 | 30 | 3 | 45 |
| M0P200BT10 | 200 | 30 | 3 | 45 |
| M0P210BT10 | 210 | 30 | 3 | 45 |
| M0P255BT10 | 255 | 30 | 3 | 45 |
| M0P310BT10 | 310 | 30 | 3 | 45 |
| M0P330BT10 | 330 | 30 | 3 | 45 |
| M0P410BT10 | 410 | 30 | 3 | 45 |
| M0P455BT10 | 455 | 30 | 3 | 45 |
| M0P510BT10 | 510 | 30 | 3 | 45 |
| M0P600BT10 | 600 | 30 | 3 | 45 |
| M0P630BT10 | 630 | 30 | 3 | 45 |
| M0P100CT15 | 100 | 35 | 3 | 45 |
| M0P130CT15 | 130 | 35 | 3 | 45 |
| M0P200CT15 | 200 | 35 | 3 | 45 |
| M0P210CT15 | 210 | 35 | 3 | 45 |
| M0P255CT15 | 255 | 35 | 3 | 45 |
| M0P310CT15 | 310 | 35 | 3 | 45 |
| M0P330CT15 | 330 | 35 | 3 | 45 |
| M0P410CT15 | 410 | 35 | 3 | 45 |
| M0P455CT15 | 455 | 35 | 3 | 45 |
| M0P510CT15 | 510 | 35 | 3 | 45 |
| M0P600CT15 | 600 | 35 | 3 | 45 |
| M0P630CT15 | 630 | 35 | 3 | 45 |
| M0P100DT15 | 100 | 35 | 4 | 45 |
| M0P130DT15 | 130 | 35 | 4 | 45 |
| M0P200DT15 | 200 | 35 | 4 | 45 |
| M0P210DT15 | 210 | 35 | 4 | 45 |
| M0P255DT15 | 255 | 35 | 4 | 45 |
| M0P310DT15 | 310 | 35 | 4 | 45 |
| M0P330DT15 | 330 | 35 | 4 | 45 |
| M0P410DT15 | 410 | 35 | 4 | 45 |
| M0P455DT15 | 455 | 35 | 4 | 45 |
| M0P510DT15 | 510 | 35 | 4 | 45 |
| M0P600DT15 | 600 | 35 | 4 | 45 |
| M0P630DT15 | 630 | 35 | 4 | 45 |
| M0P100ET15 | 100 | 40 | 4 | 45 |
| M0P130ET15 | 130 | 40 | 4 | 45 |
| M0P200ET15 | 200 | 40 | 4 | 45 |
| M0P210ET15 | 210 | 40 | 4 | 45 |
| M0P255ET15 | 255 | 40 | 4 | 45 |
| M0P310ET15 | 310 | 40 | 4 | 45 |
| M0P330ET15 | 330 | 40 | 4 | 45 |
| M0P410ET15 | 410 | 40 | 4 | 45 |
| M0P455ET15 | 455 | 40 | 4 | 45 |
| M0P510ET15 | 510 | 40 | 4 | 45 |
| M0P600ET15 | 600 | 40 | 4 | 45 |
| M0P630ET15 | 630 | 40 | 4 | 45 |
| M0P100FT15 | 100 | 50 | 4 | 45 |
| M0P130FT15 | 130 | 50 | 4 | 45 |
| M0P200FT15 | 200 | 50 | 4 | 45 |
| M0P210FT15 | 210 | 50 | 4 | 45 |
| M0P255FT15 | 255 | 50 | 4 | 45 |
| M0P310FT15 | 310 | 50 | 4 | 45 |
| M0P330FT15 | 330 | 50 | 4 | 45 |
| M0P410FT15 | 410 | 50 | 4 | 45 |
| M0P455FT15 | 455 | 50 | 4 | 45 |
| M0P510FT15 | 510 | 50 | 4 | 45 |
| M0P600FT15 | 600 | 50 | 4 | 45 |
| M0P630FT15 | 630 | 50 | 4 | 45 |
